Isotop® is a solution combining spring and shock absorbing elements, used to dampen the propagation of low-frequency vibrations. It is used in ventilation and air conditioning systems, pumps, fans, cooling towers and refrigerators, among other applications.
Isotop® insulators are characterized by excellent Getzner® quality, low settling and maximum precision in operation. They offer a long service life and can be tuned up to a frequency of 3 Hz.
Natural frequency: 3.5 Hz
Load range: 3-90 kg
Min/max range: 20-1000 N
Height (no load): 57 mm
Natural frequency: 3.5 Hz
Load range: 117-800 kg
Nominal range: 1000-7900 N
Height (no load): 75 mm
Natural frequency: 3.2 Hz
Load range: 20-525 kg
Min/max range: 120-6400 N
Height (no load): 94 mm
Natural frequency: 3.2 Hz
Load range: 690-4730 kg
Min/max range: 1,000-45,000 N
Height (no load): 114 mm
Natural frequency: 5.3-9.5 Hz
Load range: 11-100 kg
Height (no load): 57 mm
Natural frequency: 5.3-6.6 Hz
Load range: 215-1590 kg
Height (no load): 75 mm
Natural frequency: 4.2-5.6 Hz
Load range: 24-650 kg
Min/max range: 250-7500 N
Height (no load): 94 mm
Natural frequency: 4.3-5.2 Hz
Load range: 400-5850 kg
Min/max range: 1,000-54,000 N
Height (no load): 114 mm
Natural frequency: 7.4-9.2 Hz
Load range: 6-35 kg
Min/max range: up to 350 N
Height (no load): 45 mm
Natural frequency: 9.9-12.1 Hz
Load range: 4-95 kg
Height (no load): 28 mm
Natural frequency: 3.2-3.5 Hz
Load range: 3-420 kg
Min/max range: 500-3000 N
Height (no load): 105-190 mm
Natural frequency: 3.2-3.5 Hz
Load range: 3-420 kg
Min/max range: 50-750 N
Height (no load): 105-190 mm
Natural frequency: up to 3.5 Hz
Min/max range: 50-500 kN
Natural frequency: 7-12 Hz
Load range: 8-4135 kg
Min/max range: up to 10,000 N
Height (no load): 49-117 mm
Natural frequency: up to 10 Hz
Min/max range: up to 2600 N
Natural frequency: up to 7.5 Hz
Min/max range: up to 40,000 N
Natural frequency: 7.5-9.6 Hz
Load range: 90-2050 kg
Height (no load): 51.5 mm
Natural frequency: 10.8-12.7 Hz
Load range: 63-930 kg
Height (no load): 33 mm
Natural frequency: 5.7-10.4 Hz
Load range: 105-3480 kg
Min/max range: 650-27,000 N
Height (no load): 111-149 mm
Natural frequency: 9.7-10.9 Hz
Load range: 61-260 kg
Min/max range: up to 20,000 N
Height (no load): 118 mm
Broszura Rozwiazania wibroizolacyjne technicznego wyposazenia budynkow PL.pdf
(PDF, 1.1 MB)
Product Catalogue Machine Bearings for Building Services Equipment (HVAC) EN.pdf
(PDF, 3.0 MB)
Zestawienie Wieszaki wibroizolacyjne Getzner Isotop PL.pdf
(PDF, 2.0 MB)
Data Sheet Isotop MSN EN.pdf
(PDF, 91 KB)
Data Sheet Isotop SD EN.pdf
(PDF, 101 KB)
Data Sheet Isotop ENI EN.pdf
(PDF, 79 KB)
Data Sheet Isotop MSN-BL EN.pdf
(PDF, 97 KB)
Data Sheet Isotop MSN-DAMP EN.pdf
(PDF, 131 KB)
Data Sheet Isotop MSN-Z MSN-Z-LC SD-Z EN.pdf
(PDF, 113 KB)
Data Sheet Isotop DSD EN.pdf
(PDF, 125 KB)
Data Sheet Isotop DSD-BL EN.pdf
(PDF, 174 KB)
Data Sheet Isotop SD-BL EN.pdf
(PDF, 132 KB)
Data Sheet Isotop DMSN EN.pdf
(PDF, 121 KB)
Data Sheet Isotop Compact EN.pdf
(PDF, 274 KB)
Data Sheet Isotop DZE EN.pdf
(PDF, 229 KB)
Data Sheet Isotop FP FP-K EN.pdf
(PDF, 264 KB)
Schematische Darstellung Isotop DSD-FPK-NV1-9 DE.pdf
(PDF, 490 KB)
Data Sheet Isotop BL EN.pdf
(PDF, 581 KB)
Data Sheet Isotop DSD-BL EN.pdf
(PDF, 587 KB)
Data Sheet Isotop Compact EN.pdf
(PDF, 375 KB)
Data Sheet Isotop DZE EN.pdf
(PDF, 273 KB)
Installation Guideline Isotop SE pro and Isotop SE light EN.pdf
(PDF, 464 KB)
Installation Guideline Isotop DT EN.pdf
(PDF, 218 KB)
Installation Guideline Isotop NV and FP-K EN.pdf
(PDF, 241 KB)
Getzner® is a world leader in the production of vibration isolation materials. Its products are distinguished by high quality and many years of durability, which is extremely important for materials on which entire buildings or their floors stand.
We are pleased to announce that we are the official distributor of Getzner® products in Poland. In doing so, we provide full analytical support, selection and verification of the effectiveness of solutions. Regardless of the specifics of your order, you will always receive a product of the highest quality.
Our employee will help in the selection of Isotop or send additional documents.
